Step 2 - Installing vega.js

bower install d3 vega
or
npm install d3 vega

Step 3 - Calling vega

function parse(spec,id) {
  vg.parse.spec(spec, function(chart) {
    var view = chart({ el:id });
    view.viewport(null)
      .renderer("svg")
      .update();
  });
}
parse("charts/chart.json","#vis");

Step 4 - Visualization

"width": 800,
"height": 300,
"padding": {"top": 10, "left": 30, "bottom": 30, "right": 10},
"data": [
  {
    "name": "table",
    "url": "data/data.csv",
    "format": {
      "type": "csv",
      "parse": {
        "date": "date"
      }
    }
  }
]

Step 5 - Scales

"scales": [
  {
    "name": "x",
    "type": "time",
    "range": "width",
    "domain": {"data": "table", "field": "date"}
  },
  {
    "name": "y",
    "type": "log",
    "range": "height",
    "domain": {"data": "table", "field": "version"}
  }
]

Step 6 - Axes

"axes": [
  {"type": "x", "scale": "x"},
  {"type": "y", "scale": "y"}
]

Step 7 - Marks

"marks": [
  {
    "type": "symbol",
    "from": {"data": "table"},
    "properties": {
      "enter": {
        "x": {"scale": "x", "field": "date"},
        "y": {"scale": "y", "field": "version"},
        "stroke": {"value": "#80bd01"},
        "fill": {"value": "#80bd01"}
      },
      "update": {
        "size": {"value": 10},
        "fillOpacity": {"value": 1}
      },
      "hover": {
        "size": {"value": 40},
        "fillOpacity": {"value": 0.5}
      }
    }
  }
]

Result - Node versions

Step 9 - Marks Groups

{
  "type": "group",
  "from": {
    "data": "nodeversions",
    "transform": [{"type": "facet", "groupby": ["engine"]}]
  },
  "marks": [
    {
      "type": "symbol",
      "properties": {
        "enter": {
          "x": {"scale": "x", "field": "date"},
          "y": {"scale": "y", "field": "version"},
          "fill": {"scale": "color", "field": "engine"},
          "stroke": {"scale": "color", "field": "engine"}
        },
        "update": {
          "size": {"value": 15},
          "fillOpacity": {"value": 1}
        },
        "hover": {
          "size": {"value": 40},
          "fillOpacity": {"value": 0.5}
        }
      }
    }

Step 10 - Text Marks in specific dates

{
  "type": "text",
  "from": {
    "transform": [{"type": "filter", "test": "datum.date == time('2015-01-14')"}]
  },
  "properties": {
    "enter": {
      "x": {"scale": "x", "field": "date", "offset": -20},
      "y": {"scale": "y", "field": "version"},
      "fill": {"scale": "color", "field": "engine"},
      "text": {"field": "engine"},
      "baseline": {"value": "middle"}
    }
  }
}

Step 11 - Tooltip - Signals

"signals": [
  {
    "name": "tooltip",
    "init": {"expr": "{date:time('2009-06-11'),version:0.3}"},
    "streams": [
      {"type": "symbol:mouseover", "expr": "datum"},
      {"type": "symbol:mouseout", "expr": "{}"}
    ],
    "transform": [
      {"type": "sort", "by": "orginalversion"}
    ]
  }
]

Step 12 - Tooltip - Predicates

"predicates": [
  {
    "name": "tooltip", "type": "==",
    "operands": [{"signal": "tooltip._id"}, {"arg": "id"}]
  }
]

Step 13 - Tooltip - Rules

{
  "type": "text",
  "properties": {
    "enter": {
      "fill": {"value": "#000"}
    },
    "update": {
      "x": {"value": 6},
      "y": {"value": 14},

      "text":{
        "rule": [
          {
            "predicate": {
              "name": "tooltip",
              "id": {"value": null}
            },
            "template": ""
          },
          {"template":
          "{{tooltip.date|time:'%Y-%m-%d'}}
          ({{tooltip.version|left:1}}.{{tooltip.version|slice:1}})"}
        ]
      },

      "fillOpacity": {
        "rule": [
          {
            "predicate": {
              "name": "tooltip",
              "id": {"value": null}
            },
            "value": 0
          },
          {"value": 1}
        ]
      }
    }
  }
}

Result - The complete story
